Model CTM-3SF75H1 CTM-3SF75H2 CTM-3SF75H3 CTP
Temperature range (scalable) 150 ... 1000 °C 200 ... 1500 °C 250 ... 1800 °C 0 ... 710 °C
Operating temperature Sensor -20 ... 85 °C
Controller 0 ... 85 °C
Storage temperature Sensor -40 ... 85 °C
Controller -40 ... 85 °C
Spectral range 2.3 μm 7.9 μm
Optical resolution 75:1 10:1
System accuracy
1 2
± (0.3 % T
of rading
+ 2 °C) ±1.5 °C or
±1 %
3 5
Response time
1
± (0.1 % T
of reading
+ 1 °C)
3
±0.5 °C or
±0.5 %
3 5
Temperature coefficient
5
±0.05 K/K or ±0.05 %/K (whichever is greater)
Temperature resolution 0.1 °C
3
0.5 °C
3
Response time (90 % signal) 1 ms
4
150 ms
Emissivity / gain 0.100...1.100 (adjustable via programming keys or software)
Transmissivity 0.100...1.100 (adjustable via programming keys or software)
Signal processing Average, peak hold, valley hold (adjustable via programming keys or software)
Software (optional) CompactConnect
1) At ambient temperature 23 ±5 °C; whichever is greater (CTP)
2) Accuracy for thermocouple output: ±2.5 °C or ±1 %
3) e = 1 / Response time 1 s
4) With dynamic adaptation at low signal levels
5) For ambient temperatures (sensor): 18 °C ≤ sensor ≤ 28 °C
