Page 26
Optical Charts
thermoMETER CT
CTM-3SF22
Optics: CF
D:S: 22:1
5mm@ 110mm
D:S (far field) = 9:1
CTM-3SF33
Optics: SF
D:S: 33:1
CTM-3CF1-33
Optics: CF1
D:S: 33:1
1.0mm@ 30mm
D:S (far field) = 4:1
