Appendix
A 1 Factory Settings
The devices have following presettings at time of delivery:
Signal output object temperature 0 - 5 V
Emissivity 0.970 (CT, CTP)/1.000 (CTM-1, CTM-2, CTM-3)
Transmissivity 1.000
Averaging (AVG) 0.2 s (CTF: 0.1 s)/(CTM-1, CTM-2, CTM-3: 0.001 s)
Smart Averaging inactive/(CTF, CTM-1, CTM-2, CTM-3: active)
Peak hold (MAX) inactive
Valley hold (MIN) inactive
Lower limit signal output 0 V
Upper limit signal output 5 V
Temperature unit °C
Ambient temperature compensation
1
internal sensor temperature probe
Baud rate [kBaud] 115
1) Output at OUT-AMB as 0 - 5 V signal on CT-SF and CTP
Model CT-SF02/15/22/
CTF/CTH
CTM-1SF40 CTM-1SF75 CTM-
1SF75H1
CTM-2SF40 CTM-2SF75
Lower limit temperature range [°C] 0 485 650 800 250 385
Upper limit temperature range [°C] 500 1050 1800 2200 800 1600
Lower alarm limit [°C]
(normally closed)
30 600 800 1200 350 500
Upper alarm limit [°C]
(normally open)
100 900 1400 1600 600 1200
