Micromeritics FLEX Series User Manual

Instrument Components 3Flex Service Manual
2-6 Aug 2013
Rear Panel
The rear panel provides connections for gases, compressed air, the vacuum pump, and the power cord.
Side Panels
The side panels of the 3Flex contain the Ethernet connector, RS232 connector, and the On/Off switch,
as well as access panels to circuit boards.
Vacuum pump
connector
Gas inlets
Power cord
connector
For connecting
compressed air
Left side panel
Right side panel
