Parameter description:
z Port-based mode QoS:
The port-based QoS allows users to configure certain ports as high or low
priority To give priority level for each port:
* Select “Port” in the “Mode” column for those ports that are going to perform
port-based QoS. Click the “Apply” button.
* Click the “Port priority” button. The “Port Priority Setting” page shows up.
* Click on the drop list to specify priority levels.
* Click “Apply” to execute.
z Tag based QoS Rule 1:
The Tag based QoS decides packet priority according to the tags that adding on
the packets. To configure Tag Based QoS configuration:
* Select “Tagged” in the “Mode” column for those ports that are going to perform
tag-based QoS. Click the “Apply” button.
* Click the “Tag priority” button. The “Tag Priority Setting” page shows up.
* Select the port that you are going to configure from the drop list.
* Give the priorities as high or low for each Priority Tag types.
* Click the “Apply” button again to execute your configuration.
17
