Items Functions
Mode
Indicates if authentication is enabled or disabled on the port.
(Default: Disabled)
RADIUS IP
Set the RADIUS server IP Address
RADIUS UDP Port
Set the RADIUS server network port
RADIUS Secret
Set the RADIUS encryption key
Admin State
Sets the authentication mode to one of the following options
Auto – Requires a dot1x-aware client to be authorized by the
authentication server. Clients that are not dot1x-aware will be
denied access.
Force-Authorized – Forces the port to grant access to all
clients, either dot1x-aware or otherwise. (This is the default
setting.)
Force-Unauthorized – Forces the port to deny access to all
clients, either dot1x-aware or otherwise.
Port State
Display the current status of authentication.
Re-authenticate
Sets the client to be re-authenticated after the interval
specified by the Re-authentication Period. Re-authenticate can
be used to detect if a new device is plugged into a switch port.
Force Reinitialize
Set this 802.1x configuration to initialize by compulsion.
Statistics
Display statistics for dot1x protocol exchanges for any port.
Click “Statistics”, the following page of detailed info for each port pops up
