Appendix- Command Line Interface
Start-up and Terminal configuration
To start-up the command line interface, please connect a PC COM port to the
RS-232 connector and activate a terminal emulation software (e.g. HyperTerminal
of Windows).
The terminal emulation software should be started as the following configuration:
1. Data rate: 115200 baud.
2. Data format: 8 data bits, 1 stop bit and no parity.
3. Flow control: none.
4. Click the property icon, select settings, make sure that:
“The Function, arrow, and ctrl keys act as”: Terminal keys.
“Emulation”: VT 100.
Login/Logout Procedures
To get access to the CLI, you will have to Key in the password to pass the
authentication. The factory default value of Password is blank, or other random
value.
Note: We recommend users to configure a new password to prevent unauthorized
users from accessing to the device.
