LED for each port:
The switch provides one “1000M” LED and one “10/100M” LED for each port.
1000M LED: Shows the current transmitting/receiving speed of the port.
10/100M LED: Shows the link status and the activities on the port.
LED Status Operation
Green The port is connected at 1000 Mbps.
Blinking Green A valid link is established, and there is data
transmitting/receiving.
1000M
Off No valid link on this port or the port is connected at
10/100 Mbps.
Steady Green A valid link is established, and there is no data
transmitting/receiving.
Blinking Green A valid link is established, and there is data
transmitting/receiving.
10/100M
Off No valid link on this port or the port is connected at 1000
Mbps.
Attention：The Mini GBIC slot shares the same LED indicator with the
last 4 RJ-45 (copper) ports.
Port Operation
The auto-negotiation feature allows those ports running at one of the following
operation modes:
Media Speed Duplex Mode
Full Duplex 10 Mbps
Half Duplex
Full Duplex 100 Mbps
Half Duplex
10/100/1000 Mbps(copper)
1000 Mbps Full Duplex
1000 Mbps(Fiber)
(mini-GBIC required)
1000 Mbps Full Duplex
Note: For the last port, when both the fiber and cooper interfaces are connected, the
system adapts the fiber interface and disables the relevant cooper port automatically.
Restore Default Button
You can use this button to reset the switch or restore factory default settings. To reset
