Description:
Set or show the VLAN awareness mode for the port. VLAN aware ports will strip the
VLAN tag from received frames and insert the tag in transmitted frames (except PVID).
VLAN unaware ports will not strip the tag from received frames or insert the tag in
transmitted frames.
[<portlist>]: Port list (default: All ports).
[enable|disable]: Enable/disable VLAN awareness (default: Show awareness).
VLAN PVID [<portlist>] [<vid>|none]
Description:
Set or show the port VLAN ID. Untagged frames received on the port will be classified
to this VLAN ID. Frames classified to this VLAN ID will be sent untagged on the port.
[<portlist>]: Port list (default: All ports).
[<vid>|none]: Port VLAN ID, 1-4094 (default: Show PVID).
The 'none' option can be used for trunk links.
VLAN Frame Type [<portlist>] [all|tagged]
Description:
Set or show the accepted frame type for the port.
[<portlist>]: Port list (default: All ports).
[all|tagged]: Accept all or only tagged (default: Show frame type).
VLAN Ingress Filtering [<portlist>] [enable|disable]
Description:
Set or show VLAN ingress filtering for the port.
[<portlist>]: Port list (default: All ports).
[enable|disable]: Enable or disable VLAN ingress filtering
(default: Show current setting).
www.micronet.com.tw
Page 58 of 74
