D5CUB System Board Manual
Section 2: Configuring the D5CUB
Table 2-3 lists the available processor supply voltages and the corre-
sponding jumper settings that select them.
Table 2-4 provides the jumper settings that set the D5CUB for the Intel
P54C or P55C processor.
Table 2-5 lists the types of TAG SRAMs that can be used on the
D5CUB and provides the jumper settings for each type.
16
Table 2-3: Power Supply Voltages Selection
Table 2-4: CPU Type Selection (P54C/P55C)
CPU Supply Voltage JP3
3.3V (P54C/P54CT) 1-2 STD
3.4V (P54C/P54CT) 2-3 VR
3.5V (P54C) 4-5 VRE
TAG SRAM Type JP1
Aster 16K x 8 1-2
Winbond 16K x 8 OFF
32K x 8 2-3
Table 2-5: TAG SRAM Type
Pentium CPU Type Selection JP8
P55C VCORE (2.5V) 1-2
P54C/Other VCC (3.4V) 2-3
P55C VCORE (2.8V) 4-5
