D5CUB System Board Manual
Section 3: Installing the D5CUB
31
Installing the Sound Interface Card
The D5CUB can accommodate an optional sound inter-
face card. Follow the steps below to install the sound
interface card:
1. Turn the computer system off and remove its cover.
2. Remove the slot cover of the sound interface slot
(located at the far left hand side of the D5CUB system
board).
3. Insert the sound interface card (refer to Figure 3.4)
with the bottom edge level to the slot. Never insert the
card at an angle.
4. Carefully push the card straight down, making sure
the card is fully inserted.
5. Replace the screw which holds the card in place.
6. Replace the computer cover.
