D5CUB System Board Manual
Appendix A: Technical Information
57
A
Appendix
Technical Information
Specifications
Part Number: 09-00287-01
Processor: Single ZIF socket 7 for Intel Pentium
75-200MHz and Pentium Overdrive
processors.
Standard VR and VRE Support.
Cyrix 6x86
Chipset: Intel 430HX PCIset.
Intel PIIX 3.
SMC669/UMC8669/ALI M5113 I/O
chip.
CPU Clock Select: Frequency synthesizer chip. Jumper
selectable CPU speed.
Form Factor: Baby AT size system board (8.5" x 13")
Expansion: Three 32-bit PCI slots.
Two 16-bit ISA slots.
One shared PCI/ISA slot.
BIOS: Award BIOS on 1MB Flash.
Auto-detection of memory size.
Auto-detection and display of ECC
and EDO memory.
Auto-configuration of IDE hard disk
drives.
RAM Capacity: 4MB to 256MB.
Supports EDO (Extended Data Out)
memory.
Keyboard/Mouse: Standard AT style.
PS/2 Mouse Connector.
