Cable to be used for installation is to be selected with a temperature rating of greater than 25°
Celsius above the maximum ambient temperature.
The metric cable entries are fitted with an internal stop. This will result in threads of the cable
gland being visible. Do not over tighten.
The installation and local regulations and standards determine the overall cable specification.
This section specifies suitable cable characteristics to ensure correct operation of the flame
detector. There are several different wiring methods available, as detailed in 3.3.1 and 3.3.2 of
this manual.
