4.5.2
Video
The video cabling should be a twisted pair stranded cable with an overall screen. Where multi-
core cables are used then individual screened twisted pairs are recommended. The cable should
have the following characteristics:
Table
4: Video (Twisted
Pair) Cable Characteristics
The maximum cable length is dependent on the cable manufacturer’s attenuation specification,
which is approximately proportional to conductor size.
This document is strictly private and confidential, reproduction without Micropack approval is prohibited. © Micropack Engineering Ltd, 2015
Cable
Characteristic
Characteristic
Impedance
Capacitance
Conductor
Resistance
Attenuation @
1MHz
Inductance
Nominal
150R
50nF/km - - - - - -
Absolute Limit
90R to 150R
100nF/km
150R
6dB 7mH/km
The characteristic impedance of a transmission line is a function of the physical dimensions of
the conductor and the permittivity of the dielectric (the insulation), at high frequencies this is
approximately equivalent to:
Zo (  )  L

 C
E
q
uation 1: Characteristic Im
p
edance
Calculation
For maximum performance the video output of the FDS301 is designed for differential twisted
pair operation. For single ended output a Micropack VTP4 or differential to single ended balun
should be used.
4.5.3
RS485 Communication
The RS485 communications cabling should be a twisted pair stranded cable with an overall
screen. Where multi-core cables are used then individual screened twisted pairs are
recommended. The cable should have the following characteristics:
Table
5:
RS485
Communications
Cable
Characteristics
The maximum cable length is dependent on the cable manufacturers’ attenuation specification,
which is approximately proportional to conductor size. The characteristic impedance of a
transmission line is the same as for the video above.
micro
p
ack.co.uk
Cable
Characteristic
Characteristic
Impedance
Capacitance
Conductor
Resistance
Attenuation @
1MHz
Inductance
Nominal
120R 50nF/km - - - -
- -
Absolute Limit
90R to 120R
100nF/km
120R 6dB
7mH/km
L = Cable Inductance (mH)
C = Cable Capacitance (uF)
Zo = Characteristic Impedence (Ohms)
