HELP US TO HELP YOU
Every effort has been made to ensure the accuracy in the contents of our documents; however,
Micropack (Engineering) Ltd can assume no responsibility for any errors or omissions in our
documents or their consequences.
Micropack (Engineering) Ltd would greatly appreciate being informed of any errors or omissions
that may be found in our documents. To this end we include a form, given in Appendix B, for you
to photocopy, complete and return to us so that we take the appropriate action. Thank you.
CONTENTS
TABLE
OF
This document is strictly private and confidential, reproduction without Micropack approval is prohibited. © Micropack Engineering Ltd, 2016
1
Introduction 4
1.1 Features 4
1.2 Visual Flame Detection 4
2
Safety Instructions 5
2.1 Warnings 5
2.2 Cautions 5
2.3 VDS EN54 part 10 Limitations of use 6
2.4 Important Safety Notices 6
3
Installation 8
3.1 Detector Enclosure 8
3.2 Mounting & Orientation 9
3.3 Wiring Procedure 11
3.3.1 4-20mA Output 12
3.3.2 Relay Output 14
3.4 Installation Checklist 15
3.4.1 Mechanical 15
3.4.2 Electrical 16
4
System Design Guidelines 17
4.1 Earthing & Screening Requirements 17
4.2 Power Supply 17
4.3 RS485 Communications 17
4.4 HART Protocol 18
4.5 Cable Selection 18
4.5.1 DC Power 19
4.5.2 Video 20
4.5.3 RS485 Communication 20
FDS301 Flame Detector FDS301 Safety and Technical Manual
2
Ref: 2200.5009 Rev: 2.3 ECN 4434
