Micropack FDS301 - 3.2 Mounting & Orientation

3.2
Mountin
g
&
Orientation
The mountin
g
bracket allows the detector’s
v
ertical
orientation
to
be
ad
j
usted from 0 to 45°,
and
allows a horizontal rotation of +/-45°.
Fi
g
ure 1: Detector Mountin
g
Bracket
&
Orientation
Status led must be
below the lens.
micro
p
ack.co.uk
FDS301 Flame Detector FDS301 Safety and Technical Manual
9
Ref: 2200.5009 Rev: 2.3 ECN 4434
