Setting Up and Starting the Part Queue
The Part Queue
4
v4.1.3, April 2012 Visionscape FrontRunner™ User’s Manual 4-3
– Store All Images
– Store Failed Images
– Store Passed Images
– Store Qualified Images (for more information about qualified
images, see “Storing Qualified Images” on page 4-4)
Note: Clicking Store No Images (the default) stops the Part Queue.
6. Click to the right of Part Queue Size (Cycles) and specify a value to
indicate the number of images to be stored by the Inspection Step.
Note: Setting the size to 0 disables the Part Queue.
7. Minimize or close the Editor window
8. Click
9. From the View Menu, select Part Queue.
FrontRunner™ displays the main Part Queue window, as shown in
Figure 4–3.
