Viewing Images in the Part Queue
The Part Queue
4
v4.1.3, April 2012 Visionscape FrontRunner™ User’s Manual 4-7
FrontRunner™ adds the expression to the upper panel.
12. When you are finished adding expressions, click OK.
Note: For detailed information about expressions, see Chapter 8 of the
Visionscape
®
Tools Reference.
Viewing Images in the Part Queue
After setting up and starting the Part Queue, you can view images in the
queue:
1. To upload Part Queue, click
Note: By default, this clears the camera.
FrontRunner™ displays a screen similar to the one in Figure 4–8.
This screen displays:
– A vertical column of images in the queue
– A green (pass)/red (fail) status for the currently selected image
– Cycle information for the currently selected image
– A larger image of the currently selected image
