SH-HC30 Height Controller System Manual
 Enter key: enter or exit the editing state.
 Function key: in the manual state, implement the function of “a key height
calibration”; in the editing state, switch the current editing parameters.
 Up arrow: in manual and automatic state, the set height value plus 1; in the
editing state, the current parameter plus one.
 Down arrow: in manual and automatic state, the set height value minus 1; in the
editing state, the current parameter minus 1.
 Display: the display functions are as follows:
1. Manual operation status: Display detector mode, operation status, set value of
height.
2. Automatic operational state: display detector mode, running state, the current
height value.
3. Editing parameter status: Display the editing parameter names and the
corresponding editing parameter values.
7.3 Description of Display
 Manual operation state: The first one displays the detection mode; the second one
displays the operation state; the last 3 digits display the set value of height.
 The first one: C: the capacitance detector mode, U: the arc voltage detector mode.
 The second one: no operation, flash between and ; manual rising: ; manual
falling: .
 The last
3 digits: in the capacitance mode, a decimal; unit: of mm; in arc voltage
mode, there is no decimal place; unit: V.
 Automatic oper
ation state: The first one displays the detection mode (as shown
above); the second one displays the operation state; the last 3 digits display the set
value of height (as shown above). The second one is described as follows:
 When is the fixed display, the cutting torch is adjusted up at high speed.
 When
is the flashing display, the regulating speed of the cutting torch is
increased.
 When
is the fixed display, the cutting torch is adjusted down at high
speed.
 When
is the flashing display, the regulating speed of the cutting torch is
reduced.
 When
is the flashing display, the cutting torch is adjusted to the place.
 When the last 3 digits are and the height value flashes, it is the high
alarm
 When
the last 3 digits are and the height value flashes, it is the low
alarm
 When the last 4 digits are and display, it is the upper limit position.
 When
the last 4 digits are and display, it is the lower limit position.
 Editing parameter status: The first one displays the parameter name; the second one
displays the equal sign ; the last 3 digits display the parameter value in the
flashing mode. In the capacitance mode, there is a digit after decimal; unit: mm; in
Page
24
