SH-HC30 Height Controller System Manual
Page
25
arc voltage mode, there is no decimal point position; unit: V. The first one is
described as follows:
 H: the upper limit value. When the height is larger than this value, it is the
high alarm. The cutting torch can only move down and cannot move up.
 L: lower limit value. When the height is lower than this value, it is the low
alarm. The cutting torch can only move up and cannot move down.
 A: the set value of height; in the automatic mode, this value is used as the
given value to adjust height automatically.
 E: Dead zone value (see 7.1).
 D: Speed regulating zone value (see 7.1).
 C: selection of detector mode (see 7.1).
 b: No board falling parameter value (see 7.1)
8. Troubleshooting
For the common faults, inspection methods and corrective measures see Table 8-1.
Table 8-1
Fault Inspection items Corrective measures
Whether it is powered on Power on
Whether the power supply voltage is normal Check the power supply
The motor does
not work
Whether it is locked-rotor motor Load reduction
No display Check the power supply Power on
Upper limit
alarm
The running exceeds the upper limit value of
machinery
Check the limit switch in
high position
Lower limit
alarm
The running exceeds the lower limit value of
machinery
Check the limit switch in
low position
Instable signal Whether the cutting board is grounded reliably Grounded firmly
Inaccurate
height
Operating environment changes
Implement “a key height
calibration”
Vibrate wildly Speed reduction zone value is too small
Increase the speed
reduction zone value d
Too slow
tracking
Speed reduction zone value is too big
Reduce the speed
reduction zone value d
Slight vibration Dead zone value is too small
Increase the dead zone
value E
Too low
accuracy
Dead zone value is too big
Reduce the dead zone
value E
