microTec
18
4.4 Ambient Temperatures during Operation
+ 10°C to +35°C
Contamination level 2
Overvoltage categorie II (CUT 4055E & CUT 4060E)
4.5 Performance
Range of section thickness: 0.5 - 60 µm
Increments: 0.5 µm from 0.5 µm to 2 µm
1 µm from 2 µm to 10 µm
2 µm from 10 µm to 20 µm
5 µm from 20 µm to 60 µm
Horizontal object advance Max. 40 mm
Vertical stroke Max. 70 mm
Specimen size: standard: 55 x 50 mm
Specimen orientation: X- and Y-Axes 8°, Z-Axis till 360°
Cutter drive: motorized manual switchover
Power consumption: P max. 150 Watt
Max. speed 150 rpm
*according to contractual agreement
