microTec
35
Utilization of the blades
In order to utilize the entire cutting edge of the blades. These blades can be pushed to
the right or to the left.
Release clamping lever. Push blade with the clamping plate to the left or the right.
Tighten clamping lever.
8.6 Clearance Angle Adjustment
Release clamping lever. Pivot the knife holder and /or the holder of the throw-away
blades into the clearance position.
The clearance angle can be read off from scale markings on both sides as an actual
value.
Tighten the clamping lever.
Empirically, suitable microtomic sections are produced at a
clearance angle of 15º. This clearance angle position is
characterized by a longer mark on the knife holder base.
9. Optional Accessories
Foot switch: Order number H150078
10. Emergency Service, Customer Service
microTec Laborgeräte GmbH
Rudolf-Diesel-Str. 47
69190 Walldorf, Germany
Phone: + 49 6227 8222-0
Fax: + 49 6227 8222-30
mail@micro-tec.de
www.micro-tec.de
