ArtixScan 120tf Installation and Operation Manual 7
2. Connect the scanner to your computer, using the provided FireWire cable.
Connect one end of the FireWire cable to your computer’s FireWire port, and
connect the other end of the cable to the scanner’s FireWire port.
The latest
Macintosh
computers (i.e., G3,
G4, later-generation
iMacs, etc.) are
equipped with a
built-in FireWire
port, usually labeled
with the “ ” logo.
Power button
6
+
For Macintosh users
6
+
For PC users
3. Press the power button on the front panel, and wait for the lights to stop blinking
and stay on steady. The scanner will be detected by your system automatically.

Microtek ArtixScan 120tf Specifications

Power

voltage	AC 90V to 264V, 47-63 Hz

Operating Environment

operating temperature	50° to 95°F (10° to 35°C)
relative humidity	20% to 80%

Scanning Specifications

scanning area	6 x 9 cm Max., 6 x 7 cm, 6 x 6 cm, 6 x 4.5 cm, 25 x 38 mm
resolution optical	4, 000 dpi x 4, 000 dpi
resolution interpolated	16, 000 dpi x 16, 000 dpi

Interfaces

firewire ports	Two
scsi ports	Two
transmission speed firewire	4 Mbytes/s
transmission speed scsi	2 Mbytes/s

Weight and Dimensions

dimensions	19.8" x 10.8" x 5.5" (504 x 274 x 142 mm)
weight	17.6 lb (8 kg)
