Microtek ArtixScan 120tf User Manual

ArtixScan 120tf Installation and Operation Manual 11
Using the 35mm Filmstrip Holder
Six frames can be mounted into the 35mm filmstrip holder.
1. Push to open the holder.
2. Flip the 35mm filmstrip face down and place it into the holder. Align the frame-by-
frame partitions on your filmstrip to match the partitions on the holder.
3. Close the 35mm filmstrip holder.
Slightly adjust the 35mm filmstrip by pushing the holder lid to ensure the
filmstrip’s partitions to match the holder’s partitions.
2
3
4
5
6
1
Caution: When the filmstrip holder is closed and the 35mm filmstrip is aligned
correctly, do not lock the holder lid against the side of the holder (indicated by an
arrow mark) by force or touch the filmstrips. If you do so, this will bend the
original and may result in out-of-focus scans.

Microtek ArtixScan 120tf Specifications

Power

voltage	AC 90V to 264V, 47-63 Hz

Operating Environment

operating temperature	50° to 95°F (10° to 35°C)
relative humidity	20% to 80%

Scanning Specifications

scanning area	6 x 9 cm Max., 6 x 7 cm, 6 x 6 cm, 6 x 4.5 cm, 25 x 38 mm
resolution optical	4, 000 dpi x 4, 000 dpi
resolution interpolated	16, 000 dpi x 16, 000 dpi

Interfaces

firewire ports	Two
scsi ports	Two
transmission speed firewire	4 Mbytes/s
transmission speed scsi	2 Mbytes/s

Weight and Dimensions

dimensions	19.8" x 10.8" x 5.5" (504 x 274 x 142 mm)
weight	17.6 lb (8 kg)
