Overview of the outputs section
The outputs section comprises
the following main areas.
Item Description
1 See “Matrices” on page 64.
2 See “Master outputs (mono and
stereo)” on page 69.
3 See “Talkback” on page 71.
4 See “Playback and recording” on
page 72.
5 See “Local monitor and phones”
on page 73.
6 See “Master outputs (mono and
stereo)” on page 69.
7 Master faders.
8 Four blue faders, which adjust to
their current assignment (for
example, groups).
9 See “Groups” on page 61.
10 See “Auxes” on page 68.
11 See “Monitors” on page 67.
12 See “Stereo returns” on page 66.
1
12
2
3
4
5
78
11
10
9
6
