USB 63
VeniceU
Operator Manual
USB sections on the control surface
Item Description
1 usb in switch This latching switch inserts the USB return to the channel,
muting the mic and line inputs.
2 usb c/o This latching switch flips the aux USB output to group output.
3 override masters to usb with matrix switch This latching switch
overrides the stereo master USB output with the matrix 1-2 output.
