86 Appendix B: Technical Specification
VeniceU
Operator Manual
External dimensions of the U16, U24 and U32 consoles. Dimensions are in millimetres (inches).
VeniceU16 = 552 (21.7”)
VeniceU24 = 760 (29.9”)
VeniceU32 = 960 (37.8”)
528 (20.8”)
263 (10.4”)
89 (3.5”)
20°
246 (9.7”)
578 (22.7”)
