Midea ESG-Inv M Series Pool Heat Pump Manual
Discharge temperature sensor(Tp) connection is port CN4 on the refrigerant system PCB
Inlet water temperature sensor (TW-in) connection, Outlet water temperature sensor (TW-out), Liquid refrigerant temperature sensor(T2), Gas refrigerant
temperature sensor(T2B) malfunction is port CN10 on the refrigerant system PCB
