MideaESG‐InvMSeriesPoolHeatPumpTechnicalManual
1 Specifications  
MODEL MSC‐70D2N8‐A MSC‐90D2N8‐A MSC‐120D2N8‐A
Powersupply 220‐240V~50Hz 220‐240V~50Hz 220‐240V~50Hz
Heating 
(A27/24.3℃,W28℃)
Capacity kW 7.16  9.15  12.50 
Ratedinput kW 0.95  1.35  1.79 
COP 7.50  6.80  7.00 
BoostHeating 
(A27/24.3℃,W28℃)
Capacity kW 10.30  12.80  14.50 
Ratedinput kW 1.56  2.13  2.28 
COP 6.60  6.00  6.35 
Heating 
(A15/12℃,W28℃)
Capacity kW 5.30  6.80  9.12 
Ratedinput kW 1.04  1.39  1.81 
COP 5.10  4.90  5.05 
BoostHeating 
(A15/12℃,W28℃)
Capacity kW 7.30  9.30  10.50 
Ratedinput kW 1.56  2.09  2.28 
COP 4.69  4.45  4.60 
Heating 
(A7/6℃,W28℃)
Capacity kW 4.40  5.00  7.60 
Ratedinput kW 1.05  1.28  1.77 
COP 4.20  3.90  4.30 
Heating 
(A2/1℃,W28℃)
Capacity kW 3.40  4.20  5.50 
Ratedinput kW 0.94  1.22  1.53 
COP 3.60  3.45  3.60 
Cooling
(A35/‐℃,W28℃)
Capacity kW 4.50  5.20  7.00 
Ratedinput kW 1.13  1.55  1.75 
EER 4.00  3.35  4.00 
Cooling
(A43/‐℃,W28℃)
Capacity kW 3.40  3.60  5.10 
Ratedinput kW 1.31  1.44  1.59 
EER 2.60  2.50  3.20 
Max.runninginput W 2200 2600 2800
Max.runningcurrent A 10.5 11.0 12.0
Compressor
Type DCRotary DCRotary DCRotary
Oiltype ESTEROILVG74 ESTEROILVG74 ESTEROILVG74
Oilcharged ml 420 420 420
Outdoorfan 
Motortype DCBrushless DCBrushless DCBrushless
Numberoffans 1 1 1
Airflow m
3
/h 3200 3800 3900
Airsideheatexchanger Type Finnedtube Finnedtube Finnedtube
Refrigerant 
Type R32 R32 R32
GWP 675 675 675
Chargedvolume kg 0.55 0.55 0.75
Throttletype EXV EXV EXV
Watersideheatexchanger Material Titanium Titanium Titanium
Watersideconnection 
Type
Internalthread
Glueconnection
Internalthread
Glueconnection
Internalthread
Glueconnection
mm φ50 φ50 φ50
Waterflowrange m
3
/h 3.1 3.9 5.4
