ESG‐InvM
7
Part2‐EngineeringData
Waterpressuredrop kPa 4.6 7.3 13.8
SoundpresssureLevel
Heating(A27/24.3℃,W28℃)
dB(A) 41 43 49
Heatingmax dB(A) 48 52 55
heatingslincemode1 dB(A) 39 39 40
heatingslincemode2 dB(A) 38 38 38
Cooling(A35/‐℃,W28℃)
dB(A) 43 45 48
Coolingmax dB(A) 43 45 48
Coolingslincemode1 dB(A) 40 41 43
Coolingslincemode2 dB(A) 39 40 40
Unitdimension(W×H×D) mm 988×426×712 988×426×712 988×426×712
Packingdimension(W×H×D) mm 1065×485×845 1065×485×845 1065×485×845
Netweight kg 46 46 50
Grossweight kg 53 53 57
Ambienttemperaturerange
Cooling ⁰C 15~43 15~43 15~43
Heating ⁰C ‐7~43 ‐7~43 ‐7~43
Waterinlettemperature
settingrange
Cooling ⁰C 12~30 12~30 12~30
Heating ⁰C 10~40 10~40 10~40
Nominaloutletwater
temperaturerange
Cooling ⁰C 10~28 10~28 10~28
Heating ⁰C 12~42 12~42 12~42
TheabovedatatestreferencestandardEN14511;EN50564:2011;12102:2011;OJ2014/C207/02:2014
2 Electricalcharacteristics
Model
Outdoor unit Power current Compressor Fan motor
Voltage
(V)
Hz
Min.
(V)
Max.
(V)
MCA
(A)
TOCA
(A)
MFA
(A)
RLA
(A)
kW
FLA
(A)
MSC-70D2N8-A 230 50 198 264 10.5 14.0 16.0 6.8 0.05 0.4
MSC-90D2N8-A 230 50 198 264 11.0 14.0 16.0 9.3 0.08 0.5
MSC-120D2N8-A 230 50 198 264 12.0 14.0 16.0 10.0 0.11 0.7
Note：
MCA:Min.circuitamps.(Forwirediameterselection)
TOCA:Totalover‐currentamps(Forair‐breakswitchselection)
MFA:Max.fuseamps(Forfuseselection)
RLA:Ratedloadamps.TheinputampsofcompressorwheremaximumHzcanoperatefornominalcoolingorheatingtest
condition
kW:Ratedmotoroutput
FLA:Fullloadamps.
