Midea LSBLG365/MCFN

Flooded type water cooled screw chiller (PCB Control) MCAC-CTSM-2012-11
26
(12) The wiring ports for remote start/stop, flow switch, cool/warm switch, water pump linked control,
alarm indication, etc. are reserved in the electrical cabinet of the unit.
(13) Passive inching button is used for remote start and stop, and the flow switch must be
connected to the NO contact, or the machine cannot be started.
Passive holding switch is used for cool/warm switch, e.g. common selection switch. Controls of
large power electrical appliances such as water pump and user electric heating must be
interfaced with a relay, or the PCB might be burned. Other outputs can be directly connected to
indicator lamps or alarms.
2. Electric parameter table
Power Table
Model
Main power Power Range
Quantity
of comp.
Rated
current
/A
Starting
current
/A
Max.
running
current/A
V Hz
Highest/
+%
Lowest/
-%
LSBLG365/MCFN 380 50 +10 -10 1 106 810 113
LSBLG465/MCFN 380 50 +10 -10 1 133 875 143
LSBLG560/MCFN 380 50 +10 -10 1 162 1340 174
LSBLG750/MCFN 380 50 +10 -10 1 208 1990 224
LSBLG825/MCFN 380 50 +10 -10 2 253 810*2 271
LSBLG925/MCFN 380 50 +10 -10 2 266 875*2 286
LSBLG1120/MCFN 380 50 +10 -10 2 324 1340*2 348
LSBLG1230/MCFN 380 50 +10 -10 2 359 1430*2 385
LSBLG1500/MCFN 380 50 +10 -10 2 417 1990*2 462
