Midea LSBLG365/MCFN

Flooded type water cooled screw chiller (PCB Control) MCAC-CTSM-2012-11
7
5. Specification
Single head:
Item Model
LSBLG365
/MCFN
LSBLG465
/MCFN
LSBLG560
/MCFN
LSBLG750
/MCFN
Cooling Capacity
kW 364 465 560 750
RT
103．5
132.3 159.3 213.3
Refrigerant model - R134a
Refrigerant charged kg 210 240 240 250
COP(Kw/kw) 5.87 5.96 5.89 6.15
Oil charge Liter HBR-B04/ 35 HBR-B04/ 39 HBR-B04/ 39 HBR-B04/ 41
Power supply 380V, 3Ph, 50Hz
Compressor
Type Semi-hermetic screw compressor
Quantity 1 1 1 1
Capacity adjusting 25%,50%,75%,100%
Power input kW 62 78 95 122
Rated current A 106 133 162 208
Evaporator
Type Shell-and-tube evaporator
Water flow
volume
m
3
/h 63 80 96 129
Pipe diameter mm DN125 DN125 DN150 DN150
Water pressure
drop
kPa 39 39 38 40
Water side
workin
g
MPa 1.0 1.0 1.0 1.0
Condenser
Type Shell-and-tube condenser
Water flow m
3
/h 73 94 113 150
Pipe diameter mm DN125 DN125 DN150 DN150
Water pressure
drop
kPa 51 52 51 55
Water side
working
MPa 1.0 1.0 1.0 1.0
Dimension
Length mm 3500 3500 3640 3640
Width mm 1400 1400 1420 1420
Height mm 1680 1750 1970 1970
Shipping weight kg 3000 3120 3420 3930
Running weight kg 3300 3520 3840 4380
Notes:
Nominal cooling capacities are based on following conditions: Chilled water inlet/outlet temperature
12/7℃ (53.6F/44.6F); Cooling water inlet/outlet temperature 30/35℃ (86F/96F).
The design fouling factor for both evaporator and condenser are 0.086m2/kW (0.0005ft2 F.hr/Btu),
otherwise can be customized.
