Midea LSBLG365/MCFN

Flooded type water cooled screw chiller (PCB Control) MCAC-CTSM-2012-11
8
Dual head:
Model
Item
LSBLG825
/MCFN
LSBLG925
/MCFN
LSBLG1120
/MCFN
LSBLG1230
/MCFN
LSBLG1500
/MCFN
Cooling Capacity
kW 825 924 1120 1230 1500
RT 234.6 262.7 318.5 349.7 426.5
Refrigerant model - R134a
Refrigerant charged kg 360 380 400 420 440
COP(Kw/kw) 5.57 5.92 5.89 5.86 5.95
Oil charge Liter
HBR-B04/
39*2
HBR-B04/
39*2
HBR-B04/
39*2
HBR-B04/
39*2
HBR-B04/
41*2
Power supply 380V, 3Ph, 50Hz
Compressor
Type Semi-hermetic screw compressor
Quantity 2 2 2 2 2
Capacity adjusting 25%,50%,75%,100%
Power input kW 148 156 190 210 244
Rated current A 253 266 324 359 417
Evaporator
Type Shell-and-tube evaporator
Water flow volume m
3
/h 142 159 193 212 258
Pipe diameter mm DN150 DN150 DN200 DN200 DN200
Water pressure
drop
kPa 73 77 71 71 73
Water side
working pressure
MPa 1.0 1.0 1.0 1.0 1.0
Condenser
Type Shell-and-tube condenser
Water flow m
3
/h 168 186 226 248 300
Pipe diameter mm DN150 DN150 DN200 DN200 DN200
Water pressure
drop
kPa 88 90 85 85 87
Water side working
pressure
MPa 1.0 1.0 1.0 1.0 1.0
Dimension
Length mm 4650 4650 4700 4700 4700
Width mm
1500 1500 1600 1600 1620
Height mm 1900 1900 2100 2100 2200
Shipping weight kg 5500 5700 6200 7000 7200
Running weight kg 6000 6210 6710 7680 7900
Notes:
Nominal cooling capacities are based on following conditions: Chilled water inlet/outlet temperature
12/7℃ (53.6F/44.6F); Cooling water inlet/outlet temperature 30/35℃ (86F/96F).
The design fouling factor for both evaporator and condenser are 0.086m2/kW (0.0005ft2 F.hr/Btu),
otherwise can be customized.
