Midea LSBLG365/MCFN

Flooded type water cooled screw chiller (PCB Control) MCAC-CTSM-2012-11
96
No.
中文
Part Name Quantity BOM code
1
冷凝器
Condenser
1
201790207873
1.1
左水室
Left shell cover
1
1.2
左水室垫片
Left shell sealed shim
1
1.3
直角截止阀(DN8)
Angle valve
1
201600801155
1.4
安全阀
Safty valve
1
201604100115
1.5
右水室垫片
Right shell sealed shim
1
1.6
右水室
Right shell cover
1
2
蒸发器
Evaporater
1
201790207876
2.1
右水室垫片
Right shell sealed shim
1
2.2
右水室
Right shell cover
1
2.3
直角截止阀(DN8)
Angle valve
1
201600801155
2.4
安全阀
Safty valve
1
201604100115
2.5
左水室垫片
Left shell sealed shim
1
2.6
左水室
Left shell cover
1
3
下连接板
The lower connection plate
2
201290206031
4
供液管路
Supply liquid pipe assambly
1
201690204150
4.1
干燥过滤器
Dry filter
1
201290200459
4.2
过滤器支撑
Filter support
1
4.3
垫片φ70/φ50
Shim φ70/φ50
1
4.4
节流孔板
Orifice plate
1
4.5
直通球阀(DN40)
Ball valve (DN40)
1
201601601333
4.6
电子膨胀阀(ETS100)
Electronic Expansion valve body
1
201601300035
电子膨胀阀电源线
Electronic Expansion valve power
line
1
5
引射回油管路
Oil Return Injecting pipe
assembly
1
201690204144
5.1
文丘里管
Venturi tube
1
5.2
视液镜(DN10)
Sight glass(DN10)
1
201800300003
5.3
过滤器(SR-070)
Filter (SR-070)
1
201601100151
6
油分回油管路
Oil Return pipe assmbly on oil
seperator
1
201690204147
6.1
电磁阀(FDF10MJ-1/2(G))
Solenoid Vlave
1
201600600087
6.2
视液镜(DN10)
Sight glass(DN10)
1
201800300003
6.3
过滤器(SR-070)
Filter
1
201601100151
7
上连接板
The upper connection plate
2
202990201005
8
线槽组件
Wire casing
1
201203100021
9
排气管组
Discharge pipe assembly
1
201690204096
10
螺杆式压缩机(RC2-M610)
Semi-hermetic screw compressor
1
201402101520
11
吸气管组
Suction pipe assembly
1
201690204154
12
电控柜
Electrical Control Cabinet
1
203390290646
13
氟利昂 R134a
Refrigerant
170Kg
200500100004
14
冷冻油（HBR-B04）
Refrigeration Oil
28L
200500500040
