Midea MC-SU60-RN1L Service Manual

Aqua Tempo Super II
34 201709
Midea Aqua Tempo Super II
Service Manual
1 Outdoor Unit Electric Control Box Layout
MC-SU30-RN1L
Figure 4-1.1: Electric control box front view- top layer
Main control board
Wired controller
Power supply terminal
3-way terminal
Figure 4-1.2: Electric control box front view-bottom layer
AC indicator A
AC filter board
Reactor
Inverter module
AC indicator B
Fan module
Three-phase bridge rectifier

Midea MC-SU60-RN1L Specifications

General

Brand	Midea
Model	MC-SU60-RN1L
Category	Chiller
Language	English
