4 - Diagnosis and Troubleshooting
Table 4-2.1:Outdoor unit main PCB
Power sequence detection connection
Power supply to user interface
Unit capacity dial switch
Solenoid valve(SV4) drive ports
Four-way valve drive port
Water side heat exchanger heater connections
Water flow switch heater connection
Compressor crankcase heater connections
Reserved communication port
Fan inverter module communication ports
Compressor inverter module communication ports
Wired controller communication ports
Outdoor ambient temperature sensor and air side heat exchanger refrigerant
outlet temperature sensor connections
Water side heat exchanger anti-freezing temperature sensor 1, air side heat
exchanger refrigerant total outlet temperature sensor, discharge temperature
sensor 2 and discharge temperature sensor 1 connections
Air suction temperature sensor, water side heat exchanger anti-freezing
temperature sensor 2, water side heat exchanger water outlet temperature
sensor, water side heat exchanger water inlet temperature sensor and combined
water outlet temperature sensor connections
Pressure sensor connection
Inverter module temperature sensor 1 and Inverter module temperature sensor 2
connections
AC indicator A and AC indicator B connections
Low pressure switch connection
High pressure switch and discharge temperature switch (es) connections
AC filter board communication ports
