Midea MC-SU60-RN1L Service Manual

Aqua Tempo Super II
78 201709
Midea Aqua Tempo Super II
Service Manual
Procedure 4.13.4
P7
Air side heat exchanger refrigerant outlet
temperature sensor or air side heat
exchanger refrigerant total outlet
temperature sensor is loose
1
Yes
Ensure the temperature sensor is
connected properly
No
Fan motor wiring connection is
wrong
Yes
Ensure fan motor wiring is
connected properly
No
Air side heat exchanger refrigerant outlet
temperature sensor or air side heat
exchanger refrigerant total outlet
temperature sensor has short-circuited
or failed
2
Yes
Replace the temperature sensor
No
The air side heat exchanger heat
exchange is poor
3
Yes
Inspect the system and fix the error
No
The fan or fan motor is blocked or
damaged
Yes
Inspect the system and fix the error
No
Replace outdoor main PCB
Notes:
1. Air side heat exchanger refrigerant outlet temperature sensor and air side heat exchanger refrigerant total outlet temperature sensor connection port is
CN24 and CN69 on the main PCB (labeled 22 and 23 in Figure 4-2.1 in Part 4, 2.2 “Outdoor unit main PCB”).
2. Measure sensor resistance. If the resistance is too low, the sensor has short-circuited. If the resistance is not consistent with the sensor’s resistance
characteristics table, the sensor has failed. Refer to Table 4-5.1 in Part 4, 5.1 “Temperature Sensor Resistance Characteristics”.
3. Check air side heat exchanger, fan(s) and air outlets for dirt/blockages.
