4 - Diagnosis and Troubleshooting
MC-SU60-RN1L
Figure 4-1.3: Electric control box front view-top layer
AC filter board A
Main control board
Wired controller
3-way terminal
Figure 4-1.4: Electric control box side view-bottom layer
Inverter module A
Three-phase bridge
rectifier B
Inverter module B
Reactor A
AC indicator A
Three-phase
bridge
rectifier A
Reactor B
Power supply
terminal
Fan module B
AC filter board B
AC indicator B
Fan module A
