Midea MT-200R20E20 User Manual

08
• If the water tank is completely installed outdoors, it is strongly recommended to install a rain shelter.
• When the water tank is installed outdoors, the distance between the water tank and the fence is not less than
200mm.
• When the water tank is installed indoors, the distance between the water tank and the wall is not less than 600mm.
• Forthewatertankwithelectricauxiliaryheater,theelectricauxiliaryheatershallbeatleast1000mmawayfromthe
walltoensurethatthereisenoughspaceforelectricauxiliaryheatmaintenance.
NOTE
3.2.2 Water tank installation and maintenance space, see Fig 3-3 ~ Fig 3-6. (Unit: mm)
≥200mm
≥600mm
≥600mm
Rain
Rainshed
Fig 3-4Fig 3-3
≥600mm ≥600mm
Without Aux.*
* Electric auxiliary heater is shortened to Aux.
Fig 3-6Fig 3-5
≥1000mm
≥600mm
With Aux.*
≥200mm
≥1000mm
≥600mm
Rain
Rainshed
* Electric auxiliary heater is shortened to Aux.
The Aux* is replacebale material,need to
make sure there is enough space for
e-heater maintenance.
UP
