Midea MT-200R20E20

16
5.2 Water tank temperature sensor installation
Connect the water tank temperature sensor wire connector to the outdoor unit T5L connector.
Fig.5-1
Water tank temperature sensor T5L
T5L
PCB
5.3 ODU & AUX. power connection
Ifthewatertankhastheelectricauxiliaryheating(AUX.)function,pleasefollowthestepsbelowtoconnecttheelectric
auxiliaryheatingpowercord.
NOTE
1.Removetheprotectivecoveroftheelectriccontrolboxontherightsideoftheoutdoorunit.
Fig.5-2
2.Connecttheelectricauxiliaryheatingpowerlineonthewatertanktothecorrespondingportontheterminalblock.
Terminal block
Fig.5-3
