Midea MT-200R20E20 User Manual

06
2.3Specications
Table 2-3
General
Outdoor unit model
MHW-F20WN3
Indoor unit model MT-200R26E20 MT-300R26E20
Ambient temperature °C -15~46
Leaving water temperature °C 20~60
Heating
Capacity
1
W 2600
Input W 1000
Hot water yield m
3
/h 0.0441
1
/ 0.0562
2
Refriger-
ant piping
Liquid side mm/inch φ6.35/φI/4'
Gas side mm/inch φ9.52/φ3/8'
Max.heightdi󰀨erence m 10
Max.refrigerantpipelength m 20
Design pressure MPa 3
Outdoor
unit
Outdoor unit power supply V/N/Hz 220-240/1/50
Max.current A 13.5 13.5
Compressor Type Type Rotary
Fan Type AC
Airsideheatexchanger Type Hydraulicaluminumn+Innergroovedcoppertube
Throttle Type Electricexpansionvalve
Outdoor sound pressure level dB(A) 54
Diemen-
sion
Unit dimension(L*W*H) mm 804*327*555
Packing dimension(L*W*H) mm 845*390*630
Net weight kg 29
Gross weight kg 32
Refrigerant
Type R134a
Charged volume g 900
Water
Tank
Tank volume L 200 300
Electric
heater
Capacity kW 2.1 2.1
Power supply V/N/Hz 220-240/1/50 220-240/1/50
Diemension
Unit dimension(W*D*H) mm 505*505*1665 580*580*1735
Packing dimension(W*D*H) mm 1775*635*590 1835*690*670
Net weight kg 73 96
Gross weight kg 83 108
Notes:
1. Ambient temperature 19/15°C(DB/WB), Initial water temperature 9°C, Terminative water temp. 60°C.
2. Ambient temperature 19/15°C(DB/WB), Initial water temperature 15°C, Terminative water temp. 55°C.
Fig. 2-3
Leaving water temperature
-15
Ambient temperature
55
50
60
20
-10
43 46
Unit: °C Table 2-4
Ambient
temperature
Leaving water
temperature
-15~-10 50
-10~43 60
43~46 55
