Midland Base Tech III - Adjustments and Controls; Volume Control; Squelch Control; LCD Backlight Dimmer

Base Tech III Operating Manual
5
5) Volume control
Push rotary knob, and then rotating the knob. Volume level varies from VOLO to VOL-34.
Figure 4 shows VOL-12 level
RX = = = = = = = = = =
TX = = = = = = = = = =
C001 Channel
GP VOL - 1 2
Figure 4.
6) Squelch control
Push rotary knob to select Squelch. Squelch level varies from SQL-1 to SQL-15.
Figure-5 shows SQL-9 level
RX = = = = = = = = = =
TX = = = = = = = = = =
C001 Channel
GP SQL - 9
Figure 5.
7) LCD backlight dimmer
Push rotary knob to select DIM. Dimmer level varies from DIM-0 to DIM-15. DIM-0 is the most darkest.
Figure-6 shows DIM-5 level
RX = = = = = = = = = =
TX = = = = = = = = = =
C001 Channel
GP DIM - 5
Figure 6
