Midland CT2000 instruction guide | 31
Technical specifications
Frequency band 144-146MHz & 430-440MHz (Rx / Tx)
Memory channels 203
Power supply 12,6V DC ± 10%
Operating temperature 25°C to + 55°C
Operating mode monoband/dualband
Selectable output power 25W/10W/5W
Modulation F3E(FM)
Tones 51 CTCSS / 208 DCS
Duty cycle TX 5% / RX 5% / Stand-by 90%
Max frequency deviation ≤ ±5KHz
Spurious emissions < -13dBm
Frequency stability ±1.0 ppm
Rx sensitivity @12dB SINAD < 0.3uV
Output power ≥ 3W
Dimensions 115x43x125 (LxAxP)
Weight (mike included) 858g
Specifications are subject to change without notice.
