Model MXT100
When a transmission with the correct tone is received, the mute is
removed and the voice audio can be heard. When the transmission ends
the channel is muted again. Transmissions that do not have the correct
tone are not heard.
The MXT100 has 142 Privacy Codes (38 CTCSS codes and 104 DCS
codes), which can be applied to any channel. If desired, you can select a
different Privacy Code for each channel. See CTCSS Privacy Codes
Frequency Chart and DCS Privacy Codes Chart for lists of available
Privacy Codes.
IMPORTANT! To communicate between two MXT100 radios, both
radios must be set to the same channel (see Selecting the Active
Channel) and Privacy Code selections.
To select a Privacy Code:
1. Press the Menu
button to place the radio in “Menu” mode.
2. Use the Channel Up
or Channel Down button to scroll the
menu options until the LCD display shows F1 (for CTCSS) or F2 (for
DCS), as desired.
3. Press the Menu
button again to confirm your selection.
The (for CTCSS) or (for DCS) icon will show on the LCD
display, according to your selection.
4. Use the Channel Up
or Channel Down button to scroll forward
or backward through the available Privacy Codes until the desired
Privacy Code is shown on the LCD display.
NOTE: DCS Privacy Codes 100-104 are shown on the LCD display
as A0-A4.
NOTE: Selecting a Privacy Code of “oF” will disable the Privacy
feature.
5. When the desired Privacy Code is shown on the LCD display, press the
Menu
button to confirm your selection. YOU MUST PRESS THE
MENU BUTTON TO CONFIRM YOUR SELECTION OR THE
PRIVACY CODE WILL NOT BE CHANGED.
NOTE: If you select a CTCSS Privacy Code, any pre-selected DCS
Privacy Code will be cancelled, and vice-versa.
midlandusa.com Page 17
