Model MXT100
When selecting an external speaker, ensure the speaker has 8-ohm
impedance and is rated for 4.0 watts.
NOTE: When an external speaker is connected, the radio’s internal
speaker is automatically disabled.
CONTROLS AND INDICATORS
Operating Controls
1. Volume Up – Press to increase radio volume.
2.
Channel Up – Press to scroll forward through available transmit/
receive channels.
3.
Menu – Press to place the radio in “Menu” mode. The Menu
provides options for configuring several operating parameters for your
radio.
4.
Power On/Off – Press and hold for two seconds to turn the radio
“on” or “off.”
5.
Monitor/Quiet Channel – Press to monitor the currently selected
channel for activity. Press again to exit Monitor mode.
6.
Scan – Press to enable/disable the “auto-scan” function.
7.
Channel Down – Press to scroll backward through available
transmit/receive channels.
8. LCD Display – Displays the currently selected transmit/receive
channel and other active operating parameters of the radio (see LCD
Display).
9.
Volume Down – Press to decrease radio volume.
10. Microphone Jack – Connector for external microphone (included).
midlandusa.com Page 9
