Model MXT100
Adjusting Squelch Sensitivity
The MXT100 has adjustable squelch sensitivity. The minimum squelch
level of 00 is the most sensitive, which allows the squelch to open on very
weak signals. Setting the squelch to the maximum setting of 09 requires
very strong signals to open the squelch.
To adjust the squelch sensitivity:
1. Press the Menu
button to place the radio in “Menu” mode.
2. Use the Channel Up
or Channel Down button to scroll the
menu options until the LCD display shows F3.
3. Press the Menu
button again to confirm your selection.
4. Use the Channel Up
or Channel Down button to scroll forward
or backward to select the desired squelch level, from 00 to 09.
The default squelch setting is 05, which generally provides reliable
squelch operation for most applications.
5. When the desired squelch level is shown on the LCD display, press the
Menu
button to confirm your selection. YOU MUST PRESS THE
MENU BUTTON TO CONFIRM YOUR SELECTION OR THE
SQUELCH SENSITIVITY WILL NOT BE CHANGED.
Adjusting Audible Tones (Key Beeps)
The MXT100 sounds an audible “beep” tone each time a key is pressed. If
the “beep tone” volume is too loud or too soft for your operating
environment you can adjust it from off to one of 8 different volume levels.
To adjust the “beep” tone volume level:
1. Press the Menu
button to place the radio in “Menu” mode.
2. Use the Channel Up
or Channel Down button to scroll the
menu options until the LCD display shows F4.
3. Press the Menu
button again to confirm your selection.
4. Use the Channel Up
or Channel Down button to scroll forward
or backward to select the desired “beep” tone volume level, from b0
volume off) to b8 (maximum volume level).
midlandusa.com Page 18
