9.6 STATUS UPDATE-
Used to send user status. The status numbers relates to an actual message list.
Indicates the User status (0-255) and Unit status (0-255).
To send a Status Update, Press F then Press A or B until the selection is displayed
and enter the target radio ID. Then Press D and enter the User (USR), message
number, Press D again and enter the Unit number, then Press #. If the target radio
has received the Call Alert the display should show “ACK” (acknowledgement).
Figure 18 shows Status Update ready to be sent to 366.
Status Update
To:366
USR : 1 UNT : 0 MD⌧N
Figure 18
9.7 STATUS REQUEST-
Is used to request the status of another unit. After the request is sent the target unit
should respond with the current status. In the example below USR: 2, means the
number 2 status message.
To send a Status Request, Press F then Press A or B until the selection is
displayed and enter the target radio ID then Press #. The target unit should respond
with the message number, unit ID and ACK.
Figure 19 shows Status Request received from 366.
Status Request
To:366
USR: 2 UNT: 0 MD⌧N
Fm: 00000366 (ACK)
Figure 19
