14
www.midlandradio.com
Version 5.1
680-090-2042
9.9 PREDEFINED MESSAGES-
Is used to send a predefined system message.
To send a Predefined Message, Press F then Press A or B until the selection is
displayed, then enter the target radio ID, Press D and enter a message number and
Press #. The target radio should send and ACK if successful.
Figure 20 shows message 2 ready to be sent to 366.
Short Message
To:366
Message:2 MD⌧N
Figure 20
9.10 RADIO MONITOR-
Used to key up a target radio from 10 to 60 seconds and monitor the transmit audio.
To monitor a radio, Press F then Press A or B until the selection is displayed, then
enter the target radio ID, Press D and enter 1 (10sec),2 (30sec), or 3 (60sec).
Figure 21 shows Radio Monitor request to 366 to transmit for 30 seconds.
Radio Monitor
To:366
TX Multi:1 MD⌧N
Figure 21
