• 13 •
Back of GR8
In addition to containing the outlets for the charger cables and
power cord, the back of the GR8 is the location for the serial
numbers for the charger engine and the control module. Both
numbers are necessary for warranty registration.
Serial number label
(for control module)
Cable wrap
For storing cables when not in
use.
Storage shelf
Charger cable connectors
Serial number label
(for charger engine)
AC power cord
Connection to grounded nomi-
nal 120 V outlet.
Chapter 2: OverviewGR8 1100
Midtronics Inc. 7000 Monroe Street Willowbrook, IL 60527
www.midtronics.com
