4.4 Bag Change Indicator Removal
A Dust Channel Assembly Removal, 030 4.3.
A Pull up on the silver dust channel ring to separate it from the dust channel
(the locking latch for the accessory compartment lid may also come off).
A Release the “hose” end of the indicator (without the orange tab) from its
retainer on the dust channel; pull up to remove the indicator assembly, taking
care not to lose the spring that is inside the hose.
4.5 Hinge Socket Wiring Harness Removal
A Dust Channel Assembly Removal, 030 4.3.
A Pull up on the silver dust channel ring to separate it from the dust channel
(the locking latch for the accessory compartment lid may also come off).
A Release the wiring harness plug closest to the dust channel opening.
A Push the orange tab on the bag change indicator to the right to release the
wires underneath.
A Release the rest of the hinge socket wiring from the dust channel, pulling up
on retaining tabs as necessary.
A Release the other plug from its housing at the other end of the dust channel
assembly.
Descriptive Technical Documentation
030-4 DTD no. 41-8000
